Measurement Range 1-2000000 mPa·S
Display LCD
Spindles Specification 1, 2, 3, 4
Rotating Speed of Spindles l 0.3/0.6/1.5/3/6/12/30/60 rpm / l 0.5/1/2/2.5/4/5/10/20/50/100
Interface : RS232
Automatic Switch : free selection of proper rotating speed or Spindles number.
Stable Cursor : Strip-type cursor fully charged displayed when reading basically stable
Measurement accuracy ±1%
Measurement Repeatability ±0.3%
Viscosity Resolution 1 mPa·S (If with No. 0 spindles, the resolution is 0.1 mPa.s)
Temperature probe -50 to 99 degree C
Temperature precision ± 0.5 degree C
Temperature resolution 0.1 degree
Working Condition Temperature 5-35 degree / Relative humidity no more than 80%Power AC 220V ± 10% 50 Hz ± 10%
Attachments : l No. 1, 2, 3, 4 Spindles
l Adapter
l Foundation Plate
l Up-Down Frame
l English Manual
