Technical Data :
Main circuit rated voltage: AC 380 V
Auxiliary circuit voltage: AC 220V
Rated frequency: 50 (60) Hz
Rated insulation voltage: 660V
Rated current: horizontal bus 100A
Vertical bus (MCC) 100A
Bus: three-phase five-wire system A, B, C, PE, N)
Part list:
Set of cabinets: weighing counter (2), into the line cabinet (2), the capacitor compensation cabinet (2), drawer cabinet (2), and bus connection cabinet (1).
Analog load: asynchronous motor AC380V 2.2KW 1400rpm horizontal (4 sets)
User manual
